Straight Line Wire Drawing Machine (LZ200-350)

Model

LZ200-250

LZ300

LZ350

Capstan Diameter (mm)

200-250

300

350

Max. inlet wire strength (Mpa)

About 1300

0Drawing Passes

2-12

2-12

2-12

Max. inlet wire diameter (mm)

2.5

2.8

3.6

Min. outlet wire diameter (mm)

0.3

0.6

0.6

Drawing speed (m/s)

About 20

About 20

About 20

Drawing motor Power (kW)

5.5-7.5

7.5-11

7.5-15

Straight Line Wire Drawing Machine (LZ400-450)

Model

LZ400

LZ450

Capstan Diameter (mm)

400

450

Max. inlet wire strength (Mpa)

About 1300

Drawing Passes

2-12

2-12

Max. inlet wire diameter (mm)

4.2

5

Min. outlet wire diameter (mm)

0.75

1

Drawing speed (m/s)

-20

-18

Drawing motor Power (kW)

7.5-22

11-37

Straight Line Wire Drawing Machine (LZ500-560-600)

Model	LZ500	LZ560	LZ600
Capstan Diameter (mm)	500	560	600
Max. inlet wire strength (Mpa)	About 1300
0Drawing Passes	2-12	2-13	2-9
Max. inlet wire diameter (mm)	5.5	6.5	8
Min. outlet wire diameter (mm)	1.2	1.35	1.6
Drawing speed (m/s)	About18	About15	About12
Drawing motor Power (kW)	22-45	22-55	45-75

Straight Line Wire Drawing Machine (LZ700-750-800)

Model	LZ700	LZ750	LZ800
Capstan Diameter (mm)	700	750	800
Max. inlet wire strength (Mpa)	About 1300
0Drawing Passes	2-9	2-9	2-9
Max. inlet wire diameter (mm)	10	10	14
Min. outlet wire diameter (mm)	2.2	2.2	3
Drawing speed (m/s)	About 10	About 10	About 8
Drawing motor Power (kW)	45-90	55-90	90-132

Straight Line Wire Drawing Machine (LZ900-1270)

Model	LZ900	LZ1200-1270
Capstan Diameter (mm)	LZ900	LZ1200-1270
Max. inlet wire strength (Mpa)	About 1300
0Drawing Passes	2-9	2-9
Max. inlet wire diameter (mm)	14	16
Min. outlet wire diameter (mm)	3	3
Drawing speed (m/s)	About 8	About 6
Drawing motor Power (kW)	90-132	90-160
